Optical transparent quartz lens
Optical transparent quartz lens is an optical element made of high purity fused silica by precision machining.
LUVERRE quartz
99.99%
Inner with Vacuum PVC bag and then wrapped with air bubble film, outer with wooden box.
as per customer's requirement
Optical transparent quartz lens is an optical element made of high purity fused silica by precision machining. We use quartz materials with a purity of over 99.99%, combined with advanced cold processing and hot forming processes, to produce quartz lenses with excellent optical performance, thermal stability, and chemical stability, designed specifically for harsh optical environments.
Core product advantages
1. Excellent optical performance
-High transmittance: maintains excellent transmittance in the ultraviolet to infrared spectral range (170nm-2500nm)
-Low thermal expansion coefficient: 5.5 × 10 ⁻⁷/℃, ensuring dimensional stability under temperature changes
-High uniformity: The refractive index uniformity reaches ± 1 × 10 ⁻⁶, ensuring imaging quality
2. Excellent physical and chemical properties
-High temperature resistance: Long term working temperature can reach 1100 ℃, short-term tolerance is 1450 ℃
-Radiation resistance: resistant to gamma and X-ray radiation, does not change color or deteriorate
-Chemical inertness: Resistant to most chemical corrosion except hydrofluoric acid and hot phosphoric acid
3. Precision machining capability
-Surface accuracy: up to λ/10 @ 632.8nm
-Surface accuracy: better than λ/4
-Surface roughness: Ra<5 Å (ultra smooth surface optional)
Main application areas
Research and high-end instruments
-Deep ultraviolet lithography system
-High power laser optical system
-Astronomical observation instruments
-Synchrotron radiation beamline
-Spectral analysis equipment
Industrial and Medical
-Semiconductor manufacturing equipment
-Medical laser treatment equipment
-High temperature observation window
-Optical components of analytical instruments
National Defense and Aerospace
-Spacecraft observation window
-High energy laser weapon system
-Adverse environment monitoring equipment
The industry pain points we can solve
1. Optical failure in high-temperature environments: replacing ordinary optical glass to solve deformation and atomization problems at high temperatures
2. UV band transmission loss: providing a complete solution from deep ultraviolet to vacuum ultraviolet
3. Attenuation of radiation environment performance: Ensure long-term stable operation in radiation environments such as nuclear and space
4. Fracture caused by thermal shock: Excellent thermal shock resistance, able to withstand rapid temperature changes
5. Chemical corrosion damage: Maintain optical surface integrity in corrosive environments
Customized service capability
Material selection
-Standard JGS1, JGS2, JGS3 Quartz Materials
-Imported Heraeus, Corning equivalent materials
-Doped custom quartz (doped with elements such as Ce and Ti)
Processing specifications
-Diameter range: 2mm-500mm
-Focal length range: 5mm-5000mm
-Lens types: plano convex, biconvex, plano concave, biconcave, meniscus, non spherical, cylindrical
-Coating options: anti reflective film (UV-VIS-NIR), high reflectivity film, spectral film, special function film
Design and Verification
-Optical design support and optimization
-Interference detection report provided
-Environmental testing verification (high and low temperature, humidity, vibration)
Why choose us?
1.We are more experienced.
We have over 18 years production experience of quartz items.
2.We are more efficient.
We reply customers’ requests within 24 hours and we have high efficient production, engineers and sales team.
3.Our quality is more guaranteed.
We control the quality from quartz lumps to quartz sand and then quartz products, we have better and stricter quality control than other manufactures.
4.We are able to produce more difficult quartz products.
We have large grinding platforms and precision etching machines which enable us to produce large sizes of quartz plates, tubes and high size precision quartz items.
Customer Application Cases
Case 1: European Synchrotron Radiation Facility Upgrade Project
Challenge: A focusing lens group that needs to withstand high-energy radiation and work in a high vacuum environment
Solution: Customized JGS1 quartz material non spherical lens group with ultra smooth surface treatment (Ra<3 Å)
Result: Continuous operation for 3 years without performance degradation, maintaining a transmittance of over 98.5%
Case 2: American semiconductor equipment manufacturer
Challenge: Lens for 193nm lithography machine, requiring extremely low thermal expansion and defect density
Solution: Adopt high uniformity quartz material (△ n<5 × 10 ⁻⁷) and special annealing process
Result: Batch consistency reached 99.8%, helping customers increase the yield rate by 2.3%
Case Three: Asian Space Research Institutions
Challenge: The satellite observation system window needs to withstand extreme temperature cycles (-150 ℃ to+120 ℃)
Solution: Customized thermal stabilization treatment for quartz windows, with special edge packaging design
Result: Through simulated space environment testing, it has been successfully applied to three Earth observation satellites
Empower your innovation with precision optics. If you are looking for reliable optical transparent quartz lens solutions or have special customization needs, please contact us immediately for customized solutions. Our engineering team will provide you with professional advice within 24 hours.
