1-6000mm UVC quartz tube
1-600mm UVC quartz tube, made of high-purity quartz material, specially designed for deep ultraviolet sterilization.
LUVERRE quartz
99.99%
Inner with Vacuum PVC bag and then wrapped with air bubble film, outer with wooden box.
as per customer's requirement
1-600mm UVC quartz tube, made of high-purity quartz material, specially designed for deep ultraviolet sterilization. Has excellent UVC transmittance and can efficiently kill bacteria and disinfect. Its high temperature resistance and corrosion resistance ensure long-term stable operation. Widely used in hygiene and safety fields such as water treatment, air purification, food preservation, and medical disinfection.
Our company specializes in producing 1-600mm UVC quartz tubes, which are made of high-purity synthetic quartz material and designed specifically for ultraviolet sterilization (UVC), photochemical reactions, and special lighting applications. The product diameter range covers 1mm to 600mm, and the length can be customized according to needs. It has excellent UV transmittance, thermal stability, and chemical corrosion resistance, meeting the strict requirements of industrial, medical, scientific research, and environmental protection fields.
Core product advantages
1. Excellent optical performance
-The UV transmittance is over 90% (254nm wavelength), ensuring the efficiency of UVC radiation output
-Low hydr
oxyl content (<5ppm), reducing UV absorption loss
-Uniform material density to avoid light scattering and energy decay
2. Excellent physical and chemical stability
-High temperature resistance: softening point up to 1250 ℃, long-term working temperature up to 950 ℃
-Low coefficient of thermal expansion (5.5 × 10 ⁻⁷/℃), strong thermal shock resistance
-Acid and alkali resistant, suitable for harsh chemical environments
3. Precision manufacturing process
-Internal and external surface smoothness Ra ≤ 0.2 μ m, reducing pollutant adhesion
-The wall thickness uniformity error is controlled within ± 0.1mm
-Customizable end shapes (flat mouth, flanged, frosted, sealed, etc.)
Main application areas
-Water treatment system: UV disinfection equipment for municipal drinking water, swimming pools, and sewage treatment plants
-Air purification: HVAC system, hospital air disinfection machine, biosafety cabinet
-Surface sterilization: disinfection of food packaging, medical devices, and laboratory equipment
-Photochemical reactions: chemical synthesis, photocatalysis, ozone generation equipment
-Special lighting: UV curing, printing, semiconductor manufacturing
-Research instruments: Spectral analysis, UV detection equipment
Customized service capability
We provide comprehensive customization based on specific application scenarios of our customers:
-Size customization: diameter 1-600mm, length up to 3000mm
-Shape customization: straight pipe, bent pipe, irregular pipe, double-layer sleeve, etc
-Surface treatment: inner wall coating (such as TiO ₂), outer wall sanding, fluorescent coating
-Accessory integration: electrode interface, temperature measuring hole, pre machining of bracket connection parts
-Performance optimization: specific wavelength transmittance improvement, anti fouling coating, enhanced mechanical strength
Key issues to be addressed
1. Low UVC output efficiency: Traditional quartz tubes have insufficient light transmittance, resulting in a 30-50% decrease in sterilization efficiency
2. Short service life: Ordinary quartz tubes are prone to aging and rapid attenuation of transmittance in high temperature environments
3. Poor application adaptability: Standard sizes cannot meet the space limitations of special devices
4. High maintenance costs: severe pipe wall pollution, frequent cleaning, and increased operating costs
5. Chemical compatibility issue: Quartz tubes are prone to corrosion and rupture in corrosive environments
Customer Case (Anonymous)
1. European water treatment company: customizes 300mm diameter and 2500mm length UVC quartz tubes for its large municipal water plants, increasing the light transmittance from the industry average of 85% to 92% and reducing the frequency of UV tube replacement by 30% annually
2. American medical equipment manufacturer: Developing portable air disinfection machines requires specially curved quartz tubes. We provide solutions with an inner diameter of 50mm and a 180 ° bend to help customers reduce product volume by 40%
3. Japanese semiconductor company: used for UV curing process in chip manufacturing, requiring quartz tubes to work continuously at 300 ℃ without performance degradation. Our product has been running stably for more than 18 months
4. Australian research institution: The photochemical reactor requires a double-layer quartz sleeve structure, and we have achieved precise control of the inner and outer tube spacing at 0.5mm ± 0.05mm to meet the experimental accuracy requirements
Whether you need standard size UVC quartz tubes or customized for special applications, our engineering team will provide you with the most suitable material solutions. Please provide your specific application parameters (size, working environment, performance requirements, etc.), and we will send a detailed technical solution and quotation within 24 hours.
Luverre Quartz manufactures and sells a wide range of high quality fused quartz glass, including fused quartz tubes, fused quartz plates, fused quartz rods, fused quartz windows, fused quartz crucibles, fused quartz boats, fused quartz flanges, fused quartz beakers, fused quartz glass instruments, and more. We can meet all kinds of customized requirements for fused quartz glass products.
For more information, please feel free to contact us.
Why choose us?
1.We are more experienced.
We have over 18 years production experience of quartz items.
2.We are more efficient.
We reply customers’ requests within 24 hours and we have high efficient production, engineers and sales team.
3.Our quality is more guaranteed.
We control the quality from quartz lumps to quartz sand and then quartz products, we have better and stricter quality control than other manufactures.
4.We are able to produce more difficult quartz products.
We have large grinding platforms and precision etching machines which enable us to produce large sizes of quartz plates, tubes and high size precision quartz items.
