80mm diameter quartz rod
The 80mm diameter quartz rod is made of synthetic or natural high-purity quartz material, which is melted at high temperature and precision controlled molding process.
LUVERRE quartz
99.99%
Inner with Vacuum PVC bag and then wrapped with air bubble film, outer with wooden box.
as per customer's requirement
80mm diameter quartz rod
Why do you need an 80mm diameter quartz rod?
Q: I am looking for high-purity, large-diameter quartz materials for high-temperature observation windows or precision instrument components. Ordinary glass or small-sized quartz rods cannot meet my needs. What should I do?
Answer: Our 80mm diameter quartz rod is designed specifically for this type of requirement - it provides excellent thermal stability, high transparency, and mechanical strength, directly solving your material bottleneck in large-sized, high-precision applications.
Q: Our semiconductor heat treatment process requires load-bearing rods that are resistant to high temperatures and low crystallization, with extremely high requirements for dimensional accuracy and purity. How can we ensure reliability?
Answer: This quartz rod is made of high-purity quartz sand (SiO ₂ ≥ 99.99%), which maintains low thermal expansion and high deformation resistance at high temperatures, significantly improving process stability and equipment life.
Q: We need to customize quartz rods with different lengths, end face treatments, or special coatings. Can we respond quickly and ensure consistency?
Answer: We support full-size customization and surface treatment, from cutting, polishing to coating processes can be configured as needed, and provide batch consistency guarantee to shorten your supply chain cycle.
Product Overview
The 80mm diameter quartz rod is made of synthetic or natural high-purity quartz material, which is melted at high temperature and precision controlled molding process. It has a standard diameter of 80mm (tolerance ± 0.5mm) and can be customized in length as needed (usually 100-2000mm). Suitable for harsh environments such as high temperature, corrosion, precision optics, and semiconductors.
Key features and advantages
1. Excellent thermal performance
-Resistant to high temperatures up to 1200 ℃ (short-term capacity up to 1450 ℃), with a thermal expansion coefficient as low as 5.5 × 10 ⁻⁷/℃, reducing the risk of thermal stress rupture.
-Excellent light transmittance at high temperatures (UV to IR band), suitable for applications such as observation windows and heating tubes.
2. Excellent chemical stability
-Acid resistant (except for hydrofluoric acid and hot phosphoric acid), resistant to metal slag erosion, and has a much longer lifespan in corrosive environments than ordinary glass.
3. Balance of mechanical and optical performance
-The compressive strength is greater than 1100MPa, the Mohs hardness is 7, and the surface can be polished to Ra ≤ 0.1 μ m, meeting the requirements of precision components.
Typical application scenarios
-Semiconductor and Photovoltaic Industry: Diffusion Furnace, CVD Reaction Tube Carrier Rod, Wafer Bracket.
-Optics and laser equipment: optical base, laser cavity, ultraviolet transmission window.
-High temperature industry: melting observation window, thermocouple protection tube, high-temperature furnace lining components.
-Laboratory research: customized reaction vessels, spectrometer components, vacuum system components.
Customized service scope
We support full customization of dimensions, processes, and testing:
-Flexible size adjustment: Within the range of diameter 60-200mm and length 50-3000mm, production can be carried out as needed, supporting irregular cutting and end face processing.
-Surface treatment options: including flame polishing, mechanical polishing, matte treatment, and anti reflective coating (UV/IR band).
-Special performance enhancement: Low OH content (<5ppm) models can be provided to reduce infrared absorption, or modified varieties such as titanium/cerium can be added.
-Quality verification support: Provide third-party testing reports (purity, dimensional tolerances, spectral transmittance curves, etc.).
Customer Case (Anonymous)
-California semiconductor equipment manufacturer: Purchasing 80mm diameter and 1200mm length quartz rods for a new type of diffusion furnace bracket to replace the original alumina material, reducing high-temperature deformation by 65%. The customer has been continuously purchasing for 3 years.
-Japan Institute of Optics: Customized 80mm diameter titanium doped quartz rod for high-power laser experiments, with transmission band and thermal stability fully meeting the design specifications.
-European Union industrial heating system manufacturer: jointly developed quartz carrying rods with matte surface treatment, successfully solved the problem of reflective interference in high-temperature environments, and won its supplier innovation award.
Whether it's a standard 80mm quartz rod or a fully customized solution, we are committed to providing you with reliable performance and stable supply of quartz products. If you need detailed technical parameters, customized inquiries or sample testing, please feel free to contact us at any time - let us use our professional quartz manufacturing experience to accurately match your project needs.
Luverre Quartz manufactures and sells a wide range of high quality fused quartz glass, including fused quartz tubes, fused quartz plates, fused quartz rods, fused quartz windows, fused quartz crucibles, fused quartz boats, fused quartz flanges, fused quartz beakers, fused quartz glass instruments, and more. We can meet all kinds of customized requirements for fused quartz glass products.
For more information, please feel free to contact us.
Why choose us?
1.We are more experienced.
We have over 19 years production experience of quartz items.
2.We are more efficient.
We reply customers’ requests within 24 hours and we have high efficient production, engineers and sales team.
3.Our quality is more guaranteed.
We control the quality from quartz lumps to quartz sand and then quartz products, we have better and stricter quality control than other manufactures.
4.We are able to produce more difficult quartz products.
We have large grinding platforms and precision etching machines which enable us to manufactures and sells a wide range of high quality quartz glass, including quartz tubes, quartz plates, quartz rods, quartz windows, quartz crucibles, quartz boats, quartz flanges, quartz beakers, quartz glass instruments, and more.
5. About 20 years of professional experience
-Focusing on the manufacturing of quartz products for a quarter century
-The average working experience of the technical team exceeds 15 years
6.Global Service Network
-Our products are exported to over 40 countries and regions including Europe, America, Japan, South Korea, and the Middle East
-Multi language technical support (English, German, French, Spanish, Russian, Japanese)
