Long-term high temperature 1200 degree quartz glass
Quartz glass with long-term high temperature resistance of 1200 degrees is a kind of special industrial technology glass composed of high-purity silicon dioxide (SiO _ 2).
LUVERRE quartz
99.99%
Inner with Vacuum PVC bag and then wrapped with air bubble film, outer with wooden box.
as per customer's requirement
Long-term high temperature 1200 degree quartz glass
Quartz glass with long-term high temperature resistance of 1200 degrees is a kind of special industrial technology glass composed of high-purity silicon dioxide (SiO _ 2). Its excellent performance makes it particularly outstanding in high temperature environments and can meet the needs of a variety of harsh conditions.
High temperature resistance:
The softening point temperature of quartz glass is about 1730 ° C, which can be used for a long time at 1100 ° C, and the short-term use temperature can reach 1400 ° C. Its thermal expansion coefficient is very small, only 1/10 to 1/20 of that of ordinary glass, so it has good thermal shock resistance and will not break even under severe temperature changes.
Chemical stability:
Except for hydrofluoric acid, quartz glass hardly reacts chemically with other acids, and its acid resistance is 30 times that of ceramics and 150 times that of stainless steel. In high temperature environments, its chemical stability is still excellent, making it suitable for highly corrosive environments.
Optical properties:
Quartz glass has good light transmittance in the ultraviolet to infrared wavelengths, with a visible light transmittance of over 93%. It is an important material for the manufacture of optical instruments and optical communication equipment.
Other features:
Quartz glass also has the characteristics of good electrical insulation, high mechanical strength, and high hardness (Mohs hardness is 7), making it an irreplaceable advantage in a variety of fields.
Application
Due to its excellent performance, long-term high-temperature 1200-degree quartz glass is widely used in the following fields:
Laboratory equipment:
It is used in high-temperature reaction vessels, crucibles, laboratory heating equipment, etc., to meet the requirements of high purity, high temperature resistance, and corrosion resistance.
Semiconductor industry:
In the semiconductor manufacturing process, quartz glass is used in the production of single-crystal silicon crucibles, boat dishes, furnace core tubes, and bell jars. Due to its high purity and high temperature resistance, it can ensure the stability of the process.
Electric light source manufacturing:
Quartz glass is used in the manufacture of electric light source equipment such as high-pressure mercury lamps, long-arc xenon lamps, and iodine-tungsten lamps because of its light transmittance and high temperature resistance.
Chemical and metallurgical industries:
Quartz glass tubes can be used in high temperature reaction equipment, transportation pipelines, observation windows, etc., especially in strong acid or high temperature environments.
Aerospace and defense industries:
Quartz glass is used in components such as rockets, spacecraft observation windows, thermal insulation casings, nozzles, and radome to meet the needs of extreme environments.
Optical communication and optical instruments:
Quartz glass is the main material for manufacturing optical fiber preforms and high-end optical instruments (such as prisms and lenses). Its high light transmission and high temperature resistance ensure long-term stable operation of equipment.
Custom description
Due to the difficulty of processing quartz glass, customization is an important way to meet specific needs. Here are the key parameters and processes to consider when customizing:
Basic parameters:
Dimensions: diameter, length, wall thickness, etc., determined according to specific application scenarios.
Shape: straight pipe, curved pipe, U-shaped pipe or other special shapes.
Surface treatment: whether polishing, coating (e.g. high temperature resistant coating, reflective coating), etc.
Performance requirements:
Maximum operating temperature: Determine whether it is necessary to operate at 1200 ° C for a long time, or to withstand higher temperatures for a short time.
Pressure/vacuum requirements: If used in a pressure or vacuum environment, specify the pressure range.
Thermal shock resistance: whether it needs to be used in an environment with severe temperature changes.
Other special requirements:
Grinding or interface: Whether a standard grinding or non-standard interface is required to connect with other equipment.
Scale or marking: Whether it is necessary to engrave a scale or marking on the tube body for observation or measurement.
Special coating: Whether it is necessary to add special functional coatings such as corrosion resistance and anti-reflection.
Long-term high temperature 1200 degree quartz glass has been widely used in laboratory equipment, semiconductors, electric light sources, chemical industry, aerospace and other fields due to its excellent properties such as high temperature resistance, corrosion resistance, high light transmission and thermal stability. Customized services further meet the individual needs of different scenarios.
Luverre Quartz manufactures and sells a wide range of high quality quartz glass, including quartz tubes, quartz plates, quartz rods, quartz windows, quartz crucibles, quartz boats, quartz flanges, quartz beakers, quartz glass instruments, and more. We can meet all kinds of customized requirements for quartz glass products.
For more information, please feel free to contact us.
Why choose us?
1.We are more experienced.
We have over 18 years production experience of quartz items.
2.We are more efficient.
We reply customers’ requests within 24 hours and we have high efficient production, engineers and sales team.
3.Our quality is more guaranteed.
We control the quality from quartz lumps to quartz sand and then quartz products, we have better and stricter quality control than other manufactures.
4.We are able to produce more difficult quartz products.
We have large grinding platforms and precision etching machines which enable us to produce large sizes of quartz plates, tubes and high size precision quartz items.
