Small diameter transparent quartz glass rod
Small caliber transparent quartz glass rod is a precision manufactured glass component that plays a key role in many high-tech fields due to its excellent physical and chemical properties.
LUVERRE quartz
99.99%
Inner with Vacuum PVC bag and then wrapped with air bubble film, outer with wooden box.
as per customer's requirement
Small caliber transparent quartz glass rod
Small caliber transparent quartz glass rod is a precision manufactured glass component that plays a key role in many high-tech fields due to its excellent physical and chemical properties.
Small caliber transparent quartz glass rods are made from high-purity quartz glass (usually with a silicon dioxide content>99.95%) as raw material and processed through precise drawing or cutting techniques. Its diameter is usually small (ranging from a few millimeters to over ten millimeters), and its length can be customized according to demand. The product has extremely high transparency, with a visible light transmittance of over 99%, allowing for clear transmission of light. At the same time, it inherits the excellent characteristics of quartz glass: an extremely low coefficient of thermal expansion (about 5.5 × 10 ⁻⁷/° C), which makes its size extremely stable and not easily deformed under drastic temperature changes; Capable of withstanding continuous operating temperatures up to 1100 ° C or even higher; Has excellent chemical stability, acid and alkali resistance, and corrosion resistance to most chemical reagents; High hardness and good wear resistance; It also has good electrical insulation performance. Its surface is usually very smooth and has high cleanliness.
Application
Small caliber transparent quartz glass rods are widely used in the following fields due to their unique properties:
In the field of optics and optoelectronics: used as fiber optic connectors, lenses, windows, core rods for optical fibers, resonant cavity components for lasers, or light/image transmission components in optical sensors. Its high transparency and dimensional stability are crucial for ensuring precise transmission of optical signals.
Semiconductor industry: Used as a support, probe, micro fixture or transmission pipeline for heating elements in wafer processing, etching, deposition and other processes, capable of withstanding high temperatures and corrosive environments while avoiding contamination of semiconductor materials.
Laboratory and Chemical Analysis: Used for manufacturing microreactors, capillary electrophoresis columns, chromatography column packing carriers, microsamplers, or high-temperature reaction probes. Its chemical inertness and high temperature resistance ensure the accuracy and safety of experiments.
Medical and Biotechnology: It has applications in microfluidic chips, biosensors, cell manipulation tools (such as optical tweezers, microneedles), etc. Its biocompatibility and precise size meet the requirements of microscale operations.
Special lighting: Packaging components used to manufacture filament supports, light guides, or small light sources for special lighting fixtures.
Research and Measurement: Used as protective tubes for high-temperature measurement probes, micro displacement sensor components, etc.
Customized service
We provide flexible customized services for small-diameter transparent quartz glass rods to meet specific customer needs
Size customization: The diameter (minimum up to micrometer level) and length of the rod can be precisely customized according to customer requirements, achieving standardized or non-standard size production.
End face treatment: Provide services such as end face grinding, polishing, oblique cutting, or flat cutting to meet different optical or assembly requirements. It can achieve mirror level smoothness.
Surface treatment: Surface cleaning, coating (such as anti reflective film, reflective film, anti reflective film, etc.) or special coating treatment can be provided as needed.
Shape customization: In specific situations, it is possible to try customizing quartz rods with small bends, taper angles, or other special geometric shapes (complex shapes may be limited by the process).
Special specifications: For customers with special purity, bubble size, stripe size, or other optical/physical performance requirements, we can provide corresponding technical support and solutions.
We have rich production experience and a professional technical team, committed to providing customers with high-quality, high-precision, and personalized small-diameter transparent quartz glass rod products and services.
Luverre Quartz manufactures and sells a wide range of high quality quartz glass, including quartz tubes, quartz plates, quartz rods, quartz windows, quartz crucibles, quartz boats, quartz flanges, quartz beakers, quartz glass instruments, and more. We can meet all kinds of customized requirements for quartz glass products.
For more information, please feel free to contact us.
Why choose us?
1.We are more experienced.
We have over 18 years production experience of quartz items.
2.We are more efficient.
We reply customers’ requests within 24 hours and we have high efficient production, engineers and sales team.
3.Our quality is more guaranteed.
We control the quality from quartz lumps to quartz sand and then quartz products, we have better and stricter quality control than other manufactures.
4.We are able to produce more difficult quartz products.
We have large grinding platforms and precision etching machines which enable us to produce large sizes of quartz plates, tubes and high size precision quartz items.
