Transparent quartz plug tube
Transparent quartz plug tube is a tubular sealing component made of high-purity fused silica (SiO ₂ content ≥ 99.99%).
LUVERRE quartz
99.99%
Inner with Vacuum PVC bag and then wrapped with air bubble film, outer with wooden box.
as per customer's requirement
Transparent quartz plug tube
Q: I need a transparent sealing component that can maintain stability in high temperature environments. What is the solution?
Answer: Transparent quartz plug tube - made of high-purity quartz material, capable of withstanding high temperatures above 1200 ℃, providing excellent chemical stability and transparency.
Q: My production process requires customized sizes of pipeline sealing components. How can I achieve this?
Answer: We provide full-size customization services, ranging from 2mm to 200mm in diameter and 10mm to 2000mm in length, all of which can be accurately processed according to your equipment parameters.
Q: How to prevent corrosive media from corroding the connection parts in laboratories or industrial equipment?
Answer: Quartz plug tubes have excellent acid and alkali corrosion resistance, making them particularly suitable for sealing applications in harsh environments such as semiconductors, photovoltaics, and chemicals.
Transparent quartz plug tube is a tubular sealing component made of high-purity fused silica (SiO ₂ content ≥ 99.99%). Both ends can be precision ground to ensure perfect cooperation with various quartz glassware, metal flanges or special equipment. The product combines the inherent advantages of quartz materials with the practicality of engineering design, making it the preferred sealing solution for high-end manufacturing and research fields worldwide.
Key performance parameters
-Temperature resistance range: -50 ℃ to+1200 ℃ (can withstand 1450 ℃ in the short term)
-Thermal expansion coefficient: 5.5 × 10 ⁻⁷/℃ (only 1/15 of ordinary glass)
-Transmittance: Visible light band ≥ 92%, maintaining excellent transmittance from ultraviolet to infrared band
-Chemical stability: Resistant to most acid-base corrosion except hydrofluoric acid and hot phosphoric acid
-Surface accuracy: The roughness Ra of the grinding area is ≤ 0.2 μ m, ensuring no leakage in the seal
Product application areas
1. Semiconductor manufacturing industry: observation window sealing for diffusion furnaces and CVD reaction furnaces
2. Photovoltaic industry: Transparent sealing components for polycrystalline silicon ingot furnaces and cleaning equipment
3. Laboratory equipment: High temperature reaction kettle, spectrometer sample chamber, vacuum system connection
4. Chemical industry: Corrosive medium transportation pipeline sight glass, observation hole sealing
5. In the field of electric light sources: insulation and sealing components for high-power lamps
6. Scientific research instruments: Optical path sealing interfaces for synchrotron radiation and laser equipment
Product Advantage Analysis
1. Excellent thermal stability
-Extremely low coefficient of thermal expansion ensures that it does not rupture during drastic temperature changes
-The thermal shock resistance far exceeds that of ordinary glass and most ceramic materials
2. Chemical inertness guarantee
-High purity quartz does not react with most chemicals
-Long term use without pollution or precipitation, maintaining the purity of the medium
3. Possess both optical and mechanical properties
-Excellent transparency facilitates process monitoring and observation
-Hardness reaches 7 on the Mohs scale, wear-resistant and scratch resistant, with a long service life
4. Sealing reliability
-Precision grinding technology achieves vacuum sealing between metal/quartz and quartz/quartz
-Can withstand high vacuum environments above 10 ⁻⁶ Pa
Customized service capability
We understand that standardized products cannot meet all industrial needs, so we provide comprehensive customized services:
Size customization range:
-Inner diameter: 2mm -200mm (accuracy ± 0.05mm)
-Outer diameter: 3mm -220mm (accuracy ± 0.1mm)
-Length: 10mm -2000mm (accuracy ± 0.2mm)
-Wall thickness: 0.5mm-20mm (designed according to pressure requirements)
Special handling options:
-Grinding angle: 1:5, 1:10, 1:30 standard taper or custom angle
-Surface treatment: flame polishing, hydrofluoric acid etching, sandblasting treatment
-Connection end design: flat mouth, expansion mouth, flange integration
-Auxiliary processing: drilling, slotting, special chamfering, ruler scale
Material grade selection:
-Standard grade (99.99% SiO ₂) - suitable for most industrial scenarios
-High purity grade (99.99% SiO ₂) - critical processes for semiconductors and photovoltaics
-Low hydroxyl level (OH content<5ppm) - UV laser application
-Anti crystallization grade - long-term use in high-temperature environments
Problem solving ability
1. High temperature seal failure problem: Replace ordinary glass or metal seals to solve leakage caused by high temperature deformation
2. Observation window blurring issue: High transparency quartz maintains long-term clarity to avoid blind spots in process monitoring
3. Frequent replacement costs: The long lifespan of quartz materials significantly reduces maintenance costs and downtime
4. Medium contamination risk: Chemical inertness ensures no introduction of impurities, especially suitable for high-purity production environments
5. Multi device compatibility challenge: Customized production perfectly adapts to various new and old device interfaces
Customer Application Cases
Case A: European semiconductor equipment manufacturer
-Requirement: Looking for observation window sealing components that can withstand 1100 ℃ and maintain a vacuum of 10 ⁻⁶ Pa
-Solution: Customized quartz plug tube with inner diameter of 85mm and KF40 flange interface
-Effect: Running continuously for 18 months without leakage, replacing the original supplier's product, and increasing yield by 2.3%
Case B: American Solar Energy Research Institute
-Requirement: The polycrystalline silicon growth furnace requires a sealing component for the sampling port that is transparent to ultraviolet light
-Solution: Low hydroxyl quartz plug tube, diameter 45mm, integrated vacuum valve
-Effect: Achieve in-situ monitoring, reduce the number of furnace openings, and save approximately $120000 in energy consumption costs annually
Case C: Japanese chemical companies
-Requirement: Corrosion resistant sight glass components are required for pipelines transporting strong acid media
-Solution: Wall thickness reinforced quartz plug tube with PTFE sealing rings at both ends
-Effect: Safe operation for 3 years without replacement, avoiding monthly downtime and maintenance losses
Case D: China LED Chip Laboratory
-Requirement: MOCVD equipment requires custom sized quartz sealed tubes
-Solution: Non standard elliptical cross-section plug tube, perfectly matching the equipment cavity
-Effect: Shorten the equipment renovation cycle by 40 days and significantly improve the consistency of experimental data
Match professional needs and create value through customization - whether it's replacing existing components or developing new equipment, our engineering team is always ready to provide you with technical consultation and sample support. Click to contact us for the design proposal, or send your drawings/parameters directly to the inquiry email. You will receive a detailed quotation and production plan within 24 hours.
Consult now to customize your transparent quartz plug tube solution, allowing high-purity quartz technology to safeguard your equipment and processes.
Luverre Quartz manufactures and sells a wide range of high quality fused quartz glass, including fused quartz tubes, fused quartz plates, fused quartz rods, fused quartz windows, fused quartz crucibles, fused quartz boats, fused quartz flanges, fused quartz beakers, fused quartz glass instruments, and more. We can meet all kinds of customized requirements for fused quartz glass products.
For more information, please feel free to contact us.
