0.2-100mm quartz plate
0.2-100mm quartz plate, made of high-purity quartz as raw material, with a thickness covering precision to industrial grade requirements.
LUVERRE quartz
99.99%
Inner with Vacuum PVC bag and then wrapped with air bubble film, outer with wooden box.
as per customer's requirement
0.2-100mm quartz plate
0.2-100mm quartz plate, made of high-purity quartz as raw material, with a thickness covering precision to industrial grade requirements. It has excellent characteristics of high temperature resistance, UV transmittance, chemical stability, high optical transmittance, and low thermal expansion coefficient. Suitable for fields such as semiconductors, optical instruments, laboratory vessels, etc., meeting the requirements of precision machining and extreme environmental use.
As a professional quartz product manufacturer, we offer a full range of customized quartz plates with thicknesses ranging from ultra-thin 0.2mm to ultra-thin 100mm. The products are made of high-purity fused silica. Through precision processing and strict quality control, they can meet the strict demands of various industries around the world for high-performance quartz materials. Whether it is laboratory research and development or large-scale industrial applications, we can provide solutions that fully meet the requirements for size, purity, transparency, and thermal stability.
Core product advantages
1. Excellent material performance
-High purity: SiO ₂ content ≥ 99.99%, extremely low impurity content, ensuring excellent optical and chemical stability
-Thermal stability: The coefficient of thermal expansion is only 5.5 × 10 ⁻⁷/℃, with a temperature tolerance range of -200 ℃ to+1250 ℃, and outstanding thermal shock resistance
-Optical performance: Transmittance range from ultraviolet (170nm) to infrared (3500nm), with a transmittance of over 93%
-Chemical inertness: acid and alkali resistant (excluding hydrofluoric acid), suitable for highly corrosive environments
2. Precision machining capability
-Wide thickness range: 0.2-0.5mm (ultra-thin precision type), 0.5-10mm (standard type), 10-50mm (thick plate type), 50-100mm (ultra thick special type)
-Dimensional accuracy: Thickness tolerance can be controlled within ± 0.02mm, and the highest flatness can reach λ/10
-Surface treatment: We can provide various surface treatment solutions such as polishing, sanding, coating, etc
-Customized cutting: supports circular, square, and irregular cutting, with a maximum processing size of up to 2000 × 1500mm
Main application areas
Semiconductor and Optoelectronic Industry
-Wafer carrier plate, lithography machine optical platform, CVD/PVD equipment observation window
-Laser window plate, optical substrate, UV light guide device
-Problem solving: Provide low thermal expansion, high UV transmittance materials to improve process accuracy and equipment stability
Laboratory and research equipment
-High temperature observation window, spectrometer sample holder, vacuum chamber window
-Precision optical components, standard reference plates
-Problem solving: Ensure stable experimental environment and avoid material interference with experimental results
Industrial and Special Applications
-High temperature furnace observation window, chemical equipment lining plate, semiconductor heater substrate
-High power laser equipment protection, special lighting fixtures
-Solution: Extend the service life of equipment in extreme environments and reduce maintenance costs
Emerging technology fields
-Isolation windows for quantum computing devices, observation windows for spacecraft, and perspective windows for medical equipment
-New energy battery production equipment, key components for photovoltaic manufacturing
-Problem solving: Providing reliable material foundation support for cutting-edge technology
Why choose us?
Professional manufacturing experience
For 20 years, we have been dedicated to the production of quartz products, serving customers in 45+countries worldwide, and have a deep understanding of the application needs of various industries
Full chain quality control
Implement 11 quality inspection procedures from raw material screening to final shipment to ensure product consistency
Technical research and development strength
We have independently developed precision machining technology and specialized equipment, which can solve machining problems with special thickness and precision
Advantages of Foreign Trade Services
-Familiar with international logistics and import/export processes
-Provide complete technical documentation (in English/multiple languages)
-Flexible payment methods and efficient communication
Customer Case Study Sharing
Case 1: European semiconductor equipment manufacturer
-Requirement: High purity quartz carrier plate with a thickness of 0.5mm ± 0.02mm, used for the new generation of lithography equipment
-Challenge: Extremely high requirements for flatness (<0.1mm) and surface roughness (Ra<0.5nm)
-Solution: Adopt special polishing technology and specialized fixtures to achieve consistency in mass production
-Result: Customer equipment performance improved by 15%, products have been stably supplied for 3 years, and a total of 5000+pieces have been delivered
Case 2: North American Research Laboratory
-Requirement: Multiple shaped quartz observation windows for high-temperature reaction device renovation projects
-Challenge: Irregular shapes, multiple size combinations, some products require anti reflective coating
-Solution: Provide one-stop service from design optimization to coating treatment
-Result: Help the laboratory save 30% of procurement time and increase equipment operating temperature to 1100 ℃
Case 3: Asian Photovoltaic Enterprises
-Requirement: A large-sized quartz plate with a thickness of 20mm (1800 × 1200mm) for use in a new battery production line
-Challenge: Internal defect control and uniformity assurance for large-sized thick plates
-Solution: Optimize the melting process with special annealing treatment to eliminate internal stress
-Result: The product yield rate reached 99.2%, making it the designated supplier for customers
Start your customized project
Whether you need standard specifications or special applications of quartz plates, our engineering team is ready to provide you with professional advice and customized solutions. Please contact us through the website inquiry form or direct email to provide your specific needs. We will provide a preliminary plan and quotation within 24 hours.
Luverre Quartz is a manufacturer focusing on producing various quartz plates, we can produce customized quartz plates in different sizes and shapes, such as square, round, oval and other special shaped designs according to customer's requirements. The processing includes cutting, bending, welding, etc., and there are different colors available, such as transparent quartz plates, opaque quartz plates, milky quartz plates and so on.
