JGS1, JGS2 and JGS3 are fused silica materials with excellent transmittance in the ultraviolet, visible and infrared bands, which are widely used in optics, lasers, semiconductors and high-precision detection equipment. However, different application scenarios have extremely strict requirements for the cutting accuracy, dimensional tolerances, edge quality, and surface shape of quartz plates.

Frequently Asked Questions (FAQ)

Q1: What are the main differences between JGS1, JGS2, and JGS3?

A: JGS1 is deep ultraviolet quartz with a transmission range of 185-2500nm and no bubbles; JGS2 is ultraviolet visible quartz with a transmission range of 220-2500nm, allowing for a small amount of tiny bubbles; JGS3 is infrared quartz with a transmission range of 260-3500nm, suitable for near-infrared applications. The three have similar high temperature resistance and chemical stability, but different spectral characteristics.

Q2: What are the minimum thickness and maximum size that you can cut?

A: The minimum thickness can reach 0.5mm, and the maximum unilateral size can reach 600mm. It supports complex structures such as irregular cutting, step grooves, and openings, with tolerances controlled within ± 0.05mm.

Q3: How to handle the edges after cutting? Can microcracks be avoided?

A: Adopting inner circle cutting and laser cutting processes, combined with annealing treatment. We can provide edge grinding, chamfering, and polishing to effectively eliminate microcracks and improve thermal shock resistance.

Q4: Does it support small batch sampling?

A: Support. The minimum order quantity is 1 piece. After providing drawings for confirmation, a sample will be made and the sample will be verified before mass production.

What core user needs can be addressed?

-Resolve spectral matching issue: Based on your working wavelength, accurately recommend JGS1/JGS2/JGS3 to avoid a decrease in transmittance due to incorrect material selection.

-Solution to insufficient cutting accuracy: eliminate common machining defects such as edge breakage, large dimensional deviations, and rough edges.

-Resolve delivery instability: Provide customized services with multiple specifications, quick response, and stable delivery from small to large quantities.

-Resolve post-processing difficulties: Deliver finished products directly without the need for users to perform secondary trimming, drilling, or polishing.

Typical application scenarios

UV laser window: JGS1, high transmittance, low absorption, low wavefront distortion

Optical detection equipment stage: JGS2, with good flatness and resistance to wiping

Infrared thermal imaging protection window: JGS3, wide band transmission, shock resistance

Semiconductor photolithography mask plate: JGS1, bubble free, high flatness

High temperature furnace window: JGS2/JGS3, temperature resistance of 1100 ℃, good thermal stability

The value of product advantages to users

-High precision cutting: ± 0.05mm tolerance, meeting optical alignment and assembly requirements, reducing system calibration costs.

-Customization flexibility: can provide any shape such as circular, rectangular, trapezoidal, perforated, stepped, inclined, R-angle, etc.

-Surface quality controllable: The surface roughness after cutting is Ra ≤ 0.8 μ m, and can be polished to Ra ≤ 0.2 μ m.

-Batch consistency: Full size inspection report, each piece can be traced.

-Quick quotation and delivery: Standard drawings can be quoted within 24 hours, and regular thickness can be delivered within 5-7 days.

Solve practical problems for users

-Problem 1: The JGS1 window panel purchased has a broken edge, which affects its sealing performance.

Solution: We use slow cutting and edge chamfering polishing, with edge breakage controlled to be less than 0.05mm.

-Problem 2: Inconsistent thickness of quartz plates from different batches leads to optical path deviation.

Solution: Each batch of 3D dimensions will be sampled and a tolerance analysis report will be provided.

-Problem 3: Unable to find manufacturers willing to do irregular cutting.

Solution: We support CAD drawing customization, with no issues for irregular shapes, small apertures, or thin plates.

Customer Application Case (Anonymous)

Case 1: A high-end UV laser equipment manufacturer

-Requirement: JGS1 rectangular window panel, size 120 × 60 × 3mm, transmittance ≥ 90% @ 266nm, no edge breakage, surface roughness Ra ≤ 0.4 μ m.

-Solution: Using Japanese raw material JGS1, precision laser cutting+double-sided polishing, edge chamfer of 0.2mm.

-Result: 100 pieces were delivered and passed the full inspection. The customer feedback showed a significant improvement in the quality of the light spot after assembly.

Case 2: European infrared thermal imaging component supplier

-Requirement: JGS3 circular protective window with a diameter of 45.2 ± 0.02mm and a thickness of 2mm. The substrate before double-sided coating requires a sub surface damage layer of less than 10 μ m.

-Solution: Adopt wire cutting+chemical assisted polishing process to remove the processing deterioration layer.

-Result: The sample passed the DMA thermal shock test.

Case 3: A Semiconductor Testing Equipment Enterprise

-Requirement: JGS1 with stepped quartz plate, used for wafer carrier platform, length and width 180 × 180mm, middle area thickness 1.5mm, edge step thickness 3mm.

-Solution: CNC multi axis grinding+laser thickness cutting, step surface parallelism ≤ 0.01mm.

-Result: Cost reduced by 40% and delivery time shortened to 10 days.

Whether you need standard sizes or complex shaped parts, whether the thickness is as thin as 0.5mm or as large as 600mm, we can provide services such as drawing and quotation, sample delivery within 5 days, and stable batch delivery. Welcome to send CAD drawings or technical requirements to our sales team for one-on-one machining solutions and sample evaluations.

Immediately consult for a customized quotation, so that your optical design is no longer limited by quartz processing bottlenecks.
